WIKA 111.10DW 0 to 30 PSI 2" Dial Certified Pressure Gauge

WIKA 111.10DW 0 to 30 PSI 2" Dial Certified Pressure Gauge

$ 19.99

$ 0.00

Unavailable
WIKA 111.10DW 0 to 30 PSI 2" Dial Certified Pressure Gauge

WIKA 111.10DW 0 to 30 PSI 2" Dial Certified Pressure Gauge

$ 19.99

$ 0.00

Title:
  • DefaultTitle
Unavailable
Please select combo product attributes
The combo subtotal is $,SAVE$

Product Details

This is a WIKA 0 to 30 PSI 2" Dial Certified Pressure Gauge. Its part number is 111.10DW. This item comes as pictured and does not include any additional parts or accessories.

Specifications:

Manufacturer: Comair Rotron
Model # 111.10DW

Design
EN837-1 and ASME B40.100

Sizes
2", 2½" and 4" (50, 63, and 100 mm)

Accuracy class
3/2/3% of span (ASME B40.100 Grade B)

Ranges (All ranges not stocked)
Vacuum/Compound to 30" Hg (-1 bar) / 200 psi (16 bar)

Pressure from 15 psi (1 bar) to 600 psi (40 bar) or other equivalent units of pressure or vacuum (Drinking water applications typically do not exceed 300 psi/20 bar)

Working pressure
Steady: 3/4 of full scale value
Fluctuating: 2/3 of full scale value
Short time: full scale value

Operating temperature
Ambient: -40°F to 140°F (-40°C to 60°C)
Media: 140°F ( 60°C) maximum

Temperature error
Additional error when temperature changes from reference temperature of 68°F (20°C) 0.4% of span for every 18°F (10°K) rising or falling.

Pressure connection
Material: Lead-free copper alloy (lead content ≤0.25%)
Lower mount (LM)
1/4" NPT

Bourdon Tube
Material: Lead-free copper alloy
C-shape

Solder
No-lead solder

Movement
Copper alloy

Dial
White plastic with stop pin (2", 2½")
White aluminum with stop pin (4")

Pointer
Black ABS plastic (2", 2½" LM)
Black aluminum (4" LM)

Case
Black plastic

Window
Clear plastic, snap-fit
