Dake 972005 Force 100 Dura Press Hydraulic Press

Actual Product May Differ From Image Shown

The price leader for a total capability press. These Three Phase Dura Presses feature a double-acting cylinder, ram with lifting eyes, and rapid advance of the ram. They also come with a 3 HP submerged motor.

Features:

Double acting cylinder design with 5-part oil seals for smooth operation and a tight seal.
Welded heavy steel plate frame for greater rigidity.
3 HP submerged motor drives 3 centrifugal pumps for quiet, steady oil flow.
All electrical controls are low voltage (24V).
Preset and factory-sealed relief valve to prevent exceeding pressure capacity.
Ram has lifting eyes that attach a chain to hydraulically move the table.
Smooth, responsive control valve.
Rapid advance of the ram to the work piece - speed shifts automatically when contact is made.

Standard Equipment:

Frame
2 cast steel table plates (except 200-ton)
Lifting Chain
Cylinder
Pressure gauge

Specifications:

Model | Force 100
Number | 100
Horsepower | 3
Ram Speed Advance | 52
Ram Speed Pressing | 3
Width Between Uprights | 41"
Width Between Table Channels | 10"
Minimum Ram To Table | 7-7/8"
Maximum Ram To Table | 35"
Ram Travel | 19"
Base | 75" x 33"
Weight | 90"
Weight | 2950 lbs
